**ADM2486BRWZ-REEL: A Comprehensive Guide to the 7 kV Isolated RS-485 Transceiver**

In the world of industrial automation, motor control systems, and other electrically noisy environments, robust communication is paramount. The **ADM2486BRWZ-REEL** stands as a critical component in this landscape, offering a reliable and high-performance solution for serial data transmission. This integrated circuit is a **7 kV RMS, signal and power isolated RS-485 transceiver** that combines a 3-channel isolator, a ternary receiver, and a differential driver into a single, compact package.

The core strength of the ADM2486 lies in its **advanced iCoupler® technology**. This proprietary Analog Devices technology uses chip-scale transformers to achieve its impressive 7 kV RMS isolation rating. This isolation barrier is crucial as it **protects sensitive logic circuits from damaging high voltages and ground potential differences** that are common in industrial settings. By breaking ground loops and preventing noise from propagating through the system, the ADM2486 ensures data integrity and enhances system safety.

Functionally, the device operates from a single 5 V supply on both the logic and bus sides, simplifying power supply design. It supports data rates of up to **25 Mbps**, making it suitable for high-speed network applications. The transceiver is compliant with the TIA/EIA-485-A standard and features a **current-limited driver with short-circuit protection**, safeguarding the output even under fault conditions. Furthermore, its **low power consumption and failsafe receiver inputs** guarantee that the output will be in a known high state if the inputs are open or shorted, preventing communication errors.

The inclusion of **three isolated channels** (two for data and one for direction control) within one 16-lead SOIC wide body package offers a significant reduction in board space compared to solutions requiring multiple discrete components. This integration not only saves space but also improves reliability by reducing the number of external components needed.

Typical applications are extensive, ranging from **industrial field networks (PROFIBUS, Modbus)** and motor control interfaces to building automation and power inverter systems. Any application requiring long-distance, noise-immune communication between nodes at different electrical potentials can benefit from the ADM2486BRWZ-REEL.

**ICGOODFIND**: The ADM2486BRWZ-REEL is an industry-standard, highly integrated solution that delivers **robust electrical isolation, high data rates, and exceptional reliability** for harsh industrial communication networks, making it an excellent choice for designers seeking to enhance system performance and safety.

**Keywords**: RS-485 Transceiver, Electrical Isolation, iCoupler Technology, Industrial Communication, High-Voltage Protection.
